Technical Parameter
1.Chassis: 250mm U steel welded structure
2. Forming type: Chain drive
3. Diameter of axle: ¢65mm
4. Chain:16A
5. Forming motor power: 5.5kw
6. Forming speed: 8-15m/min
7. Forming rollers: 12
8. Roller material: 45# steel, coated hard chrome
9. Thickness of coated hard chrome: 0.05mm
10. Hydraulic station motor: 3kw
11. Hydraulic oil pump: Gear pump

12. Cutting type: Hydraulic cutter
13. Material of cutting part: Cr12, heat treatment HRC 58°-60°
14. Thickness of coils: 0.5-1.3mm
15. Length scale precision: ±2mm
16. Transducer: YASKAWA
17. Controlling system: PLC, touch screen
18. Power: 220V 60Hz, 3 phase, 15kw electric generator
19. Size: 5500mm×1500mm×2000mm
20. Weight: 5 tons
